型號(Item NO.)
|
全自動下壓式 Full-Automatic Push Start
|
半自動下壓式 Semi-Automatic Push Start
|
|
M-3325P
|
M-3330P
|
TM-S3325P
|
TM-S3330P
|
|
扭力
(Torque Range)
|
Kgf-cm
|
3.0~25
|
5.0~30
|
10.0~40
|
15.0~50
|
|
Lbf-in
|
2.6~21.8
|
4.4~26.1
|
8.7~34.7
|
2.6~43.5
|
|
N-m
|
0.29~2.43
|
0.49~2.91
|
--
|
0.29~1.94
|
|
空轉速r.p.m.
|
750/1000
|
600/800
|
|
適用螺絲
(m/m)
|
機械牙Ø徑
(Machine)
|
2.6~4.0(mm)
0.10~0.16(in)
|
3.0~5.0(mm)
0.12~0.20(in)
|
2.6~4.0(mm)
0.10~0.16(in)
|
3.0~5.0(mm)
0.12~0.20(in)
|
|
自攻牙Ø徑
(Tapping)
|
2.3~3.5(mm)
0.09~0.14(in)
|
2.6~4.0(mm)
0.10~0.16(in)
|
2.3~3.5(mm)
0.09~0.14(in)
|
2.6~4.0(mm)
0.10~0.16(in)
|
|
Plan Of Item
|
|
|
|
輸出扭力表(TORQUE RANGE)
|
|
POWER SUPPLY / ADAPTOR 變壓器
|
|
|
|
|
Plan
|
型號(Item NO.) TM-4130R(全自動用)
|
TM-4230R(全自動用)
|
|
型號(Item NO.) TM-S4130R(半自動用)
|
TM-S4230R(半自動用)
|
|
|
輸入電壓(INPUT) 100-120VAC 50~60Hz
|
220-240VAC 50~60Hz
|
|
輸出電壓(OUTPUT) 23VDC 120W MAX
|
|
長度(LENGTH) 135mm
|
|
重量(WEIGHT) 350g
|
|
